Smart Relays

PRODUCT HIGHLIGHTS

• Dimming Z-Wave control for 0-10 V LED drivers only (do NOT user with 120 V LED bulbs)
• Use with LED panels and fixtures with 0-10 V dimming drivers up to 4 A
• 700 series Z-Wave chip: more range, reliable coverage
• Advanced settings to customize minimum or maximum brightness level and more*
• Built-in signal repeater: keep your mesh network stable and your system fast
• SmartStart and S2 authenticated security for a truly protected smart home
• Installs behind the existing wall switch or at the fixture (check your wiring first and always follow the diagrams in the manual)
• Pigtail wires included for quicker set-up

NOTE: Z-Wave gateway controller required - sold separately. *Your smart hub/controller needs to support advanced settings and central scene programming for you to take advantage of this feature.

PRODUCT HIGHLIGHTS

• Save space and money with this smart double relay
• Control 2 switches with 1 Z-Wave device: connect the double relay to 2 120V loads for independent smart control from your Z-Wave hub or wall switch
• Great for double gang box switch automation or to add Z-Wave to a fan / light installation for individual control of the motor and bulbs
• Wires behind the wall switches or at the fixture (if you don't have a neutral in the switch box)
• 700 series Z-Wave: the latest tech for faster communication and better range
• SmartStart with S2 authenticated security with encrypted signal
• Pigtail wires for easy installation
• Smart bulb mode: disable manual and/or Z-Wave control and turn your smart bulbs on or off using wireless signal only
• Scene control: 7 multi-tap triggers available for each relay (available on hubs that support multi-tap triggers*)
• Multicolor LED indicator to guide you through the set-up process
• Compatible with quality LED and incandescent bulbs (don't connect to ballast tube lights, switched receptacles, or fans over 1/4 hp; NOTE: FEIT bulbs are not recommended)
• Acts as a Z-Wave extender: get more signal for your network with this 700 series repeater

NOTE: Z-Wave gateway controller required - sold separately. *Your smart hub / controller needs to support advanced settings and central scene programming for you to take advantage of this feature.

PRODUCT HIGHLIGHTS

• On/off Z-Wave control for 120V and dry contact applications: great for lighting control or 120V load monitoring (sump pumps, motion lights)
• 700 series Z-Wave chip: greater coverage for a stronger mesh network
• SmartStart and S2 authenticated security for a truly protected smart home
• Installs behind the existing wall switch or at the fixture (if neutral is not available in the switch box)
• Pigtail wires included for hassle-free set-up
• Perfect if you'd like to leave your favorite wall switch style or color but add Z-Wave to it
• Smart bulb mode: disable manual and/or Z-Wave control to control your smart bulbs via Z-Wave only without cutting power to them
• Scene control: choose from 7 multi-tap triggers to expand the functionality of the connected switch (available on hubs that support multi-tap triggers*)
• Multicolor LED indicator for easier pairing and diagnostics
• Compatible with quality LED and incandescent bulbs (don't connect to ballast tube lights, switched receptacles, or fans over 3A / 5 years old; NOTE: FEIT bulbs are not recommended)
• Built-in signal repeater: helps keep your network quick and reliable

PRODUCT HIGHLIGHTS

• Control DC motors and make your blinds, shades, and awnings smart
• Create schedules for morning and evening routines
• Automate your shades and awnings based on data from smart sensors, including brightness levels, temperature, and motion
• Choose from shutter or venetian mode for your motorized blinds
• Installs behind the existing wall switch or at the motor (6-32 VDC power only, momentary button switch required)
• 700 series Z-Wave chip: stronger mesh network and faster communication
• SmartStart and S2 authenticated security for a truly protected smart home
• Pigtail wires included for hassle-free set-up
• Built-in signal repeater: helps keep your network quick and reliable

NOTE: Z-Wave gateway controller required - sold separately.

PRODUCT HIGHLIGHTS

• 2 NO or NC relays to turn almost any load into a Z-Wave device (use either the normally closed or normally open relay for R1 and R2 at a time)
• 2 Dry Contact or 12-24 V inputs to monitor HVAC systems, magnetic door sensors, or analog leak alarms (use either dry contact or 12-24 V input for R1 and R2 at a time, never apply voltage to the Sw terminals)
• Automate up / down DC motors in screens, awnings, motorized blinds
• Control sprinkler systems, commercial gates, garage doors (will NOT work with MyQ or other smart openers), pool pumps, whole-house fans, landscape lighting, and more
• NEW 800 chip: more range, faster signal, SmartStart inclusion + S2 security
• SmartStart and S2 authenticated security for a truly secure smart home
• Powered by USB C or 12-24 V (AC/DC): power supply NOT included (get it here)
• Use optional wall switches for manual control of connected devices
• Wall-mount ready
